FC8135 is an outdoor access control qr code/rfid reader. It supports two verification methods: QR codes and cards, and achieves an IP66 rating for water and dust resistance. This device features Ethernet output functionality and also offers optional 485/232/Wiegand and TTL interfaces, making it suitable for a variety of scenarios. It supports connection with our Duoxian SaaS platform, enabling more convenient management for you. FC8135 is not afraid of outdoor environments and is an ideal choice whether for building installation or equipment embedded integration.
Work Online
original design
Alarm input
Stability Assurance
FC8135
Specifications
| Performance parameters | Code reading | cell phone+Paper | 2D: QRCODE, PDF417, etc. |
| One-dimensional: EAN-8, EAN-13, ISBN-10, ISBN-13, CODE39, CODE93, CODE128, UPC, ITF,etc. | |||
| Image Sensor | 640*480 CMOS | ||
| Reading direction | Tilt ±62.3° Swivel ±360° Yaw ±65.2° (15milQR) | ||
| Field of view | 86.2° (15milQR) | ||
| Identifying patterns | Active reading/passive reading, switchable | ||
| Symbol contrast | ≥25% | ||
| Reading accuracy | ≥8mil | ||
| Single scan time | 100ms/time | ||
| Reading distance | 0mm~62.4mm(QRCODE 15mil) | ||
| Scan code to give feedback | Buzzer reminder; red and green indicator lights; white fill light | ||
| Credit card support | Support reading physical card number, support reading and writing M1 card sectors | ||
| Radio Frequency Identification | Support physical ID card, NFC mobile phone, Mifare_Ultra Light, Mifare_Ultra Light 01,Mifare_One(S50), Mifare_One(S50) 02, Mifare_One(S70), Mifare_One(S70), Mifare_Pro(X), Mifare_Pro(X) 04, Mifare_Desire, Mifare_Desire 05 | ||
| Electrical/Mechanical Parameters | Product size | (L*W*H) | 75mm*65mm*35.10mm |
| Operating voltage | DC 12V-24V | ||
| Working current | 92mA (typical 12V power supply) | ||
| Rated power consumption | 1104mW (typical value 12V power supply) | ||
| Communication interface | Ethernet | ||
| Development Method | MQTT Protocol | ||
| Electrostatic protection | ±8kV (air discharge), ±4kV (direct discharge) | ||
| Environmental parameters | Operating temperature | -20℃-70℃ | |
| Storage temperature | -40℃-80℃ | ||
| Relative humidity | 5%-95% (no condensation) (ambient temperature 30°C) | ||
| Ambient light intensity | 0-80000Lux (not in direct sunlight) | ||
| operating system | Windows(xp\7\8\10), linux, Android, Mac, etc. | ||
| Certification | FCC |
